| 泵型號 | 流量Q（m 3 /h） | 工作壓力P（MPa） | 轉(zhuǎn)速n（r/min） | 效率η（%） | 允許吸上高度（m） | 配用電機(jī) | |
| 軸功率 | 功率kw | ||||||
| 50YHCB-4 | 4 | 0.6 | 960 | 60 | 5 | 1.1 | 1.5 |
| 50YHCB-8 | 8 | 0.6 | 960 | 60 | 5 | 2.2 | 3 |
| 50YHCB-12 | 12 | 0.6 | 960 | 60 | 5 | 2.4 | 3 |
| 50YHCB-15F | 15 | 0.6 | 970 | 60 | 5 | 3.8 | 2.2 |
| 50YHCB-1_ | 15 | 1.6 | 970 | 60 | 5 | 3.8 | 4 |
| 65YHCB-15 | 15 | 0.6 | 960 | 60 | 5 | 3.9 | 4 |
| 65YHCB-20 | 20 | 0.6 | 960 | 62 | 5 | 5.0 | 5.5 |
| 65YHCB-25 | 25 | 0.6 | 960 | 65 | 5 | 5.0 | 5.5 |
|
65YHCB-30
|
30 | 0.6 | 960 | 65 | 5 | 7.1 | 5.5 |
| 65YHCB-35F | 35 | 0.6 | 970 | 66 | 5 | 7.1 | 5.5 |
| 65YHCB-40 | 40 | 0.6 | 960 | 65 | 5 | 7.4 | 7.5 |
| 65YHCB-45 | 45 | 0.6 | 800 | 72 | 5 | 7.4 | 7.5 |
| 76YHCB-40 | 40 | 0.6 | 960 | 70 | 5 | 7.4 | 7.5 |
| 76YHCB-50 | 50 | 0.6 | 960 | 70 | 5 | 10.3 | 7.5 |
| 80YHCB-60 | 60 | 0.6 | 960 | 70 | 5 | 14.2 | 11 |
| 80YHCB-60A | 60 | 0.6 | 960 | 70 | 5 | 14.2 | 11 |
| 80YHCB-80 | 80 | 0.6 | 960 | 70 | 5 | 16.3 | 18.5 |
| 80YHCB-80A | 80 | 0.6 | 960 | 70 | 5 | 16.3 | 18.5 |
| 100YHCB-100 | 100 | 1.6 | 960 | 72 | 5 | 22.3 | 22 |
| 100YHCB-150 | 150 | 1.6 | 960 | 60 | 5 | 24.5 | 24 |
| 125YHCB-200 | 200 | 1.6 | 960 | 60 | 5 | 32.7 | 32 |
| 125YHCB-250 | 250 | 1.6 | 960 | 60 | 5 | 40.8 | 40 |
| 150YHCB-300 | 300 | 1.6 | 960 | 60 | 5 | 49 | 50 |
